EXCEL CITRUS JUICE EXTRACTOR

DESCRIPTION Extractor of citrus juices online, performs in a single operation the extraction of juice and essential oil without contact between them, achieving a purer flavor and protecting the quality of the juice. EXZEL in-line citrus juice extractors produce juice and essential oil completely separately in a single step, resulting in pure flavoured juice and protecting the quality of both products. completely separately in a single step, resulting in pure flavoured juice and protecting the quality of both products. Our extraction principle maximises juice production while preserving maximum juice quality. OPERATION: The upper and lower interdigitating cups capture the fruit and press it against the upper and lower cutters, which make circular cuts on both sides of the fruit. This prevents the essential oils from penetrating into the juice when squeezing. The downward movement of the upper cup pushes the fruit contents through the lower cutter into the filter tube. At the same time, the rind is ejected through the upper cup and the oil is rinsed by a water spray system and transported as an emulsion for later recovery. The perforated piston ascends inside the filter tube, causing the juice to reach the juice box, after the pulp has been filtered through the holes in the filter tube wall. Residual nuggets, membranes and fibers are expelled through the inner orifice of the piston. DEVICE DESIGN: - Cup extraction system adaptable to fruit size. - Active feeding system to guarantee the highest yield with built-in vibrating motor at the reception to ensure optimal feeding. - Separation system of essential oil contained in the rind. - Active and supervised lubrication system. - Hardened drive cams. - Safety system supervising overexertion in extraction, feeding and stop-start elements. - Cycles per minute: 65-100 - Fruit sizes: 2", 2 3/8", 3", 4", 4 1/4", 5".
